Improving Furnace Air Control & Combustion Safety with REXA

REXA recently conducted a successful installation on a crude unit heater at a refinery in California. Furnaces help refineries and petrochemical plants break down and convert hydrocarbon fluids into fuels or chemicals such as gasoline, diesel, ethylene and propylene. When making process improvements, these facilities tend to overlook improving furnace draft control. There are many different instruments to choose from when optimizing the draft in a process heater. The challenge, though, is safely elevating process fluid temperature to a target level, maximizing thermal efficiency and throughput and reducing O2, CO and NOx emissions.

This refinery suffered from many damper-related issues. Having 3 furnaces on a single Selective Catalyst Reduction (SCR) unit with all air supplied by one forced draft fan and all flue gas extracted by one induced fan, it’s imperative all dampers operate reliably. This complicated furnace/SCR arrangement includes 3 stack dampers, 3 combustion dampers, a forced draft (FD) fan suction damper and two split induced draft (I/D) fan suction dampers.

Flue Damper 1

The plant retrofitted this crude unit with balanced draft SCR equipment over 20 years ago and has experienced damper issues ever since. The dampers were replaced to fix the problem, but unfortunately the pressure drop across the dampers proved too much for the pneumatic actuators to control. This resulted in delayed damper response, causing poor draft pressure control. This led to fuel-rich operation or bogging conditions – a major safety concern.

The REXA Solution

The plant then consulted REXA to find the necessary solution. After installing the new dampers and directly mounting our actuator, plant operators almost immediately noticed a significant improvement in damper performance and air control. For the first time in decades, the crude unit started up without issue and the dampers began and continue to control better than ever before!

“REXA came in and did a demonstration for me and I could immediately see the control on an electric motor-driven hydraulic actuator was superior. I then had REXA give a demonstration for several of our engineers and they could also see the benefits of using this technology.”

– Plant Furnace Specialist

REXA actuators are installed on furnaces at many refineries across the globe. Check out our Application Spotlight below to learn more about our solution for enhanced furnace and draft control!
